The UNI-T UTi720M Thermal Imager For Android is a professional-grade infrared camera module designed to transform a standard smartphone into a high-resolution thermal imaging device. It features a robust IR resolution of 256×192 pixels, which provides 49,152 effective temperature measurement points for capturing detailed and clear thermal images. This compact and portable tool connects directly via a USB Type-C interface, allowing users to perform non-contact temperature measurements across a broad range from -20 to 200 degrees Celsius with a thermal sensitivity of 50mK.
Engineered for versatility, the UNI-T UTi720M Thermal Imager For Android offers a smooth 25Hz frame rate to ensure real-time video observation without significant lag. The device supports seven different color palettes, including Ironbow, Rainbow, and White Hot, enabling users to optimize the visual contrast based on their specific environment. It also includes advanced analytical functions such as high and low temperature auto-tracking, on-screen analyzers for points, lines, and rectangles, and an adjustable emissivity setting to maintain accuracy when measuring different material surfaces.
Durability and ease of use are central to the design of the UNI-T UTi720M Thermal Imager For Android, which features a focus-free 3.2mm lens and a 1-meter drop-proof rating. The accompanying mobile application allows for seamless photo and video recording, which can be stored directly on the phone for quick sharing or future reporting. This module is an essential asset for DIY enthusiasts, HVAC technicians, and building inspectors who need a reliable way to detect hidden issues such as water leaks, electrical faults, or heat loss in residential and industrial settings.
FEATURES:
– 256×192 thermal resolution
– Android smartphone compatible
– High definition infrared imaging
– Compact mobile phone design
– Wide temperature measurement range
– Real-time thermal analysis
– Adjustable focus lens
– Multiple color palettes
– High image frame rate
The UNI-T UTi720M Thermal Imager For Android is a professional-grade smartphone camera module designed to transform a mobile device into a high-performance thermography tool. It features a vanadium oxide uncooled sensor with an infrared resolution of 256×192 pixels, delivering clear and detailed thermal images with a total of 49,152 measurement points. This compact device connects directly via a USB Type-C interface and offers a smooth 25Hz frame rate, ensuring real-time monitoring without significant lag or motion blur during active inspections.
– High 256×192 thermal resolution
– Portable smartphone plug-and-play design
– Clear HD infrared imaging
– Compatible with Android devices
– Compact and lightweight build
– Wide temperature measurement range
– Android smartphone compatibility only
– Requires USB-C connection
– Lacks built-in battery power
– No native iOS support
– App dependent functionality
– Small physical sensor size
The UNI-T UTi720M Thermal Imager offers a high 256×192 thermal resolution and clear HD imaging in a compact, lightweight, and portable plug-and-play design that is easy to use with Android devices. It features a wide temperature measurement range, though its functionality is limited by its strict dependence on a mobile app and a USB-C connection without a built-in battery. While it provides impressive performance for its size, the device suffers from a lack of native iOS support and a small physical sensor size, making it a specialized tool exclusively for Android users. Read more…
UNI-T Smartphone Thermal Imaging Camera
The image shows a compact thermal camera designed for a smartphone. It features a silver metallic body with the UNI-T brand name on the front. A large circular lens is located on the left side with a red accent ring. A USB Type-C connector extends from the top of the device. The unit has a sleek and modern industrial design. It is built to be portable and lightweight. The edges of the device are slightly rounded for a smooth finish. This tool is used to detect heat signatures through a phone interface. The overall appearance is professional and functional.
App Interface for Thermal Imaging Adjustments
This image displays four separate smartphone app screens. The interface uses a dark background with white text. The first screen allows the user to set a distance ranging from 0.05 to 5.00 meters. The second screen provides a setting for ambient temperature between 32 and 122 degrees Fahrenheit. The third screen shows emissivity adjustments with a range from 0.01 to 1.00. The fourth screen offers a list of common materials like wood and stainless steel. Each screen includes cancel and confirm buttons at the top. The overall layout is designed to help users get more accurate readouts. Red circular icons highlight each of the three main feature categories. The text is clear and uses a sans-serif font for readability.
25Hz High Frame Rate Comparison Graphic
The image features a black background with a visual comparison between two different frame rates. The top of the image displays a heading for 25Hz high frame rate in colorful text. It includes a slogan about capturing dynamic moments and nipping hazards in the bud. A sequence of tigers appears across the center to illustrate motion. On the left side several tigers are closely spaced to represent 25Hz performance. This side is labeled as capturing 25 images per second for smooth visuals. On the right side the tigers are spaced much further apart to represent a 9Hz low frame rate. This side is labeled as capturing 9 images per second which results in stuck images. A large gold VS symbol sits in the center to highlight the difference between the two speeds. The graphic uses these animal figures to show how higher frame rates provide better detail in moving objects.
Product application guide for thermal imaging
This image shows different ways to use a thermal camera. It is a promotional graphic for a mobile phone thermal attachment. The top section is labeled HVAC inspection. A hand holds a smartphone showing a heat map of an outdoor air conditioning unit. The screen displays a bright red hot spot on the compressor. A side by side view shows the thermal image with a scale of 29.5 to 43.3 degrees Celsius. The bottom section is labeled Motor running state detection. A person uses the phone to scan a mechanical motor. The thermal view shows the motor heating up to 100.4 degrees Celsius. The background of the graphic is black with white text. It lists uses for power distribution cabinets and circuit boards. The layout uses a split screen design to compare real life views with thermal data.
Product Specifications for Thermal Imaging Device
This image displays a detailed table of product parameters for a thermal imaging camera. The table is organized into two columns with a white background and gray borders. It covers technical specifications including temperature measurement range and precision. The sensor type is listed as uncooled vanadium oxide. The thermal image resolution is 256 by 192 pixels. It mentions various color palettes like iron red and rainbow. The device supports a frame frequency of 25Hz. It connects via a Type-C USB interface. The system is compatible with Android 6.0 and above. Certifications include FCC and CE marks. Operating temperature ranges from -10 to 50 degrees Celsius. The text is written in a clear and professional font.
